Semi-Automatic Case Sealer
A semi-automatic sealer that tapes top-closed cases quickly and neatly using side belts.
- Side-belt taping
- Fast, neat results
- Domestic or imported supply
Dimensions, capacity and equipment are determined by your product; technical values may vary depending on the options selected.
Overview
Once the top flaps of a case are closed, it is fed into this machine, where side belts carry it through for fast, neat taping.
Available as domestically manufactured or imported equipment.
Technical specifications
| Min. box size | W 15 cm x L 20 cm x H 18 cm |
|---|---|
| Max. box size | W 42 cm x L 60 cm x H 50 cm |
| Output | 10 units/minute (varies by size) |
| Sealing | Tape (standard), glue / staple optional |
| Tape size used | Width 50-70 mm, length up to 800 m |
| Taping head | Italian (high efficiency) |
| Case motion | Side belts |
| Speed | Standard |
| Taping | Top and bottom taping heads |
| Machine dimensions | W 800 mm x L 1000 mm x H 1300 mm |
| Weight | 220 kg |
| Transport | Braked, mark-free polyurethane casters |
| Power supply | 220 V, 50-60 Hz |
| Warranty | 2 years mechanical, 1 year electronic |
Request a quote
Share your product and expected capacity, and we'll get back to you with a suitable configuration and price.
